| Attribute name | Attribute value |
| Model | GY-AOP |
| Total power | 3-6.5kw |
| Ozone production | 20-100G |
| Applicable water tank volume | 60-300m³ |
| Applicable water supply flow | 30-150m³/h |
| Circulation pump | 2-8m³/h |
Guanyu Company combines advanced technologies at home and abroad, adopts UV, photocatalysis, 03, advanced oxidation, high-efficiency mixing, refrigeration and other technologies, and develops and produces a new generation of products AOP products (the oxidation process with hydroxyl radicals as the main oxidant in the water treatment process is called AOPS, abbreviated as AOP). This product uses UV nano-photocatalysis + ozone technology + advanced oxidation technology to form hydroxyl radicals (0H radical) under a special reaction environment, and uses hydroxyl radicals to perform efficient advanced oxidation of organic matter in water. And thoroughly and efficiently decompose organic matter, microorganisms, pathogens, diseases, sulfides, phosphides and other poisons in the water to meet the requirements of water deodorization, disinfection, sterilization and purification. The treated water quality meets the relevant national standards. AOP products solve the problems of a single water treatment method and win the favor of the market and users with its unique technical combination advantages.
Easy installation and saves floor space.
Reliable cooling system: The equipment's cooling system and air source system have controllable and adjustable temperatures
High ozone production efficiency and concentration: Ozone concentration is greater than 120mg/L.
High-efficiency mixing, micro-nano bubbles, high solubility, large diffusion coefficient of solutes and dispersed phase storage capacity.
High-strength special ultraviolet technology, instantly produces hydroxyl free radicals.
Nano-efficient catalysis, instant decomposition and oxidation of organic matter.
Rapid, efficient and non-selective reaction. The treated water can achieve rapid oxidation of organic matter at the moment of entering and leaving the equipment. The effluent COD meets the new national emission standards or the requirements of recycled water reuse.
Organic matter can be completely degraded into carbon dioxide, and water will not produce secondary pollution. It effectively increases the transmission speed and contact time of ozone in the water body to enhance the utilization efficiency of ozone, saves ozone dosage and oxidation time, and thus greatly saves the investment and operation cost of ozone equipment
The filling of the fixed bed heterogeneous catalyst bed and the development of loaded rare metal heterogeneous catalysts strengthen the gas-liquid two-phase mass transfer and increase the reaction speed. It has the characteristics of long replacement cycle and small filling amount, which can effectively increase the utilization rate of ozone by more than 15%.
The reaction system also has auxiliary functions such as sterilization, anti-scaling, decolorization, and COD removal.
Guanyu AOP water purification equipment adopts UV photocatalysis + ozone + advanced oxidation technology. The product can be applied to water treatment systems such as secondary water supply, river management, black and odorous water bodies, swimming pools, surface water, landscape water, and aquaculture.
High-concentration ozone system
Long-term stability reaches 130mg/L, ensuring that the quality of drinking water meets the standard for a long time.
High-efficiency mixing system
The equipment's own triple mixing system: mixing pump + special high-efficiency jet mixing system + nano-microbubble cutting mixing system + drinking water tank mixing system. The efficient combination of 4 processes makes the ozone mixing efficiency not less than 70-80%.
High-concentration customized oxygen production system, imported medical-grade molecular sieve, outlet concentration 93%. The equipment has no continuous heating equipment temperature, constant oxygen temperature, modular structure, compact structure, saving air compressor, cold dryer, drying equipment, air pressure tank, etc. space and installation costs.
High-intensity, high-power customized nano-high-efficiency photocatalytic system is 3-5 times more effective than ordinary photocatalytic equipment. The sterilization and purification effect of hydroxyl radicals is several times more than that of ozone equipment and ultraviolet equipment alone.
Intelligent customizable control system:
Intelligent control system, Internet of Things intelligent control system can be customized according to user and working conditions, and can be linked with the front and back links of the system to achieve one-button start and unattended operation.
The equipment and pipelines are all made of stainless steel and customized, with a long service life, extending the equipment investment cycle by more than 20%
Completely and efficiently kill bacteria, viruses, and microorganisms in the water, especially Legionella and other stubborn colonies.
Adopting a customized high-efficiency UV system, in addition to the sterilization and disinfection functions, it also has the functions of removing residual chlorine, making the water clear and sweet, and improving the taste
Solve the secondary pollution of tap water caused by various reasons and ensure that drinking safety meets the standards.
No chemical agent addition, no bacterial microbial pollution, extend the service life of the secondary water supply system, and reduce maintenance costs
Low power consumption, energy saving, reduce operating costs, fully automatic control operation, easy to install and transport.
No light resurrection and dark resurrection of bacteria, viruses, and microorganisms.
| Drinking water AOP selection table | |||||
| Model | Ozone production | Applicable water tank volume | Applicable water supply flow | Circulation pump m³/h | Total power KW |
| GY-AOP-20 | 20G | 60m³ | 30m³/h | 2m³/h | 3 |
| GY-AOP-30 | 30G | 90m³ | 45m³/h | 4m³/h | 3.7 |
| GY-AOP-60 | 60G | 180m³ | 90m³/h | 6m³/h | 5 |
| GY-AOP-100 | 100G | 300m³ | 150m³/h | 8m³/h | 6.5 |
